Measuring elements.................Vane anemometer :
LV101 : Proximity sensor
LV107/ 110 : Hall effect sensor
Ambient temperature : Pt100 class A
Display......................................2 lines, LCD technology. Sizes 50 x 34.9 mm.
1 line of 5 digits with 7 segments ( value)
1 line of 5 digits with 16 segments ( unit)
Housing.....................................Shock-proof made of ABS, IP54 protection
Keypad......................................Metal-coated with 5 keys
Cable.........................................straight, lg. 200 mm ( LV101)
retractable, length 450 mm, up to 2.4 m when released
Conformity................................electromagnetical compatibility ( NF EN 61326-1 guideline)
Power supply............................1 alcaline battery 9V 6LR61
Operating temperature ( instrument) ..from 0 to 50° C
Operating temperature ( probe) .......from -20 to + 80° C
Storage temperature................from -20 to + 80° C
Auto shut-off.............................adjustable from 0 to 120 min
Weight.......................................190g
Languages............. ...................French, english
